IoT Device
IP68 Protection
KOMINFO CERTIFIED
Benefits
Anti-tampering function triggers automatically and sends alarm to system when sensor is away from Cyble target of meter
Compatible with water meters and gas meters that is equipped with LC sensor target
Specifications
MCU
Arm® 32-bit Cortex®-M4
Memory
256KB Flash; 64KB RAM
TX Power
Up to 22dBm
ISM Bands
AS923, AU915, EU868
Device type
Class A
Anti-tampering
Yes
RX Sensitivity
Down to -125dBm@BW = 125 kHz, SF = 7
Report interval
Configurable via Downlink Commands
Uplink channels
8 Settable channels with bandwidh of 12 kHz
Spreading factor
SF7 ~ SF10(Adaptive)
Communication mode
LoRaWAN
LBT (Listen Before Talk)
Yes
Network registration way
OTAA, ABP
LoRaWAN uplink confirmation
Confirm or Partially Confirm
Anti-dismantling alarm function
Yes
Electrical Parameters
TX Current
≤127 mA @22dBm
Battery Life
up to 5 years battery lifetime
Power Supply
3.6V (ER26500 8500mAh)
Active Current
≤5mA
Standby Current
≤70µA
Battery Usage Monitoring
Accurate coulomb measurement
Battery undervoltage warning
Yes
Temperature Parameters
Storage Temperature
-10°C ... 60°C
Working Temperature
-10°C ... 60°C
MCU Temperature Monitoring
Yes
